Stranded PVC Copper Cable 4.5 Core 4×120+70 mm, 0.6/1kV | BAHRA

Unarmored Stranded copper power cable (CU/PVC/PVC), 4.5 core, 4×120+70mm2 size conductor, Low Voltage 0.6/1kV, The cable is safe to use thanks to the double insulation and high quality materials used in its manufacture, manufactured by Bahra Cables Company, insulation color (red, yellow, blue, black, green/yellow).

• Conductor: Stranded Copper
• Insulation Material: PVC (Polyvinyl Chloride)
• Outer Sheath: PVC
• Voltage: 0.6/1kV
• Number of Cores: 4 Core + Neutral Line
• Conductor Size (Cross-Sectional Area): ( 4cx120 mm2 ) + 70mm2
• Number of Phase Wires: 37
• Number of Neutral Wires: 19
• Nominal Insulation Thickness of Phase: 1.6 mm
• Nominal Insulation Thickness of Neutral: 1.4 mm
• Nominal Sheath Thickness: 2.3 mm
• Approx Overall Diameter: 39.4 mm
• Weight: 4676 kg/km
• Length : 500 meters
• Phase Core Colors: (Red, Yellow, Blue, Black, Green/Yelllow)
• Standard: IEC 60502-1
