Stranded PVC Copper Cable Single Core 4 mm, 300/500V | Riyadh Cables

Single core stranded copper cable, 4 mm size conductor, 300/500 volts, PVC insulated, PVC sheathed, insulation color is black, produced by Riyadh Cables Company, where the outer jacket provides protection for the cable from corrosion and external factors.

• Conductor: Copper
• Conductor Shape: Stranded as per BS EN 60228
• Insulation Material: PVC (Polyvinyl Chloride)
• Outer Sheath: PVC
• Voltage: 300/500 volts
• Number of Cores: 1
• Conductor Size (Cross-Sectional Area): 4 mm
• Number of Wires: 7
• Insulation Thickness: 0.8 mm
• Sheath Thickness: 0.9 mm
• Overall Diameter or Dimensions: Lower Limit 5.4 mm / Upper Limit 6.8 mm
• Max DC Conductor Resistance at 20°C: 4.61 ohm/km
• Weight: 74 kg/km
• Insulation Color: Black
• Standard: BS 6004
