Stranded PVC Copper Cable Single Core 10 mm, 300/500V | Riyadh Cables

Single core stranded copper cable, 10 mm size conductor, 300/500 volts, PVC insulated, PVC sheathed, insulation color is brown, available in a variety of sizes and colors with highest quality and best prices, produced by Riyadh Cables Company.

• Conductor: Copper
• Conductor Shape: Stranded as per BS EN 60228
• Insulation Material: PVC (Polyvinyl Chloride)
• Outer Sheath: PVC
• Voltage: 300/500 volts
• Number of Cores: 1
• Conductor Size (Cross-Sectional Area): 10 mm
• Number of Wires: 7
• Insulation Thickness: 1 mm
• Sheath Thickness: 0.9 mm
• Overall Diameter or Dimensions: Lower Limit 7.2 mm / Upper Limit 8.8 mm
• Max DC Conductor Resistance at 20°C: 1.83 ohm/km
• Weight: 150 kg/km
• Insulation Color: Brown
• Standard: BS 6004
