Unarmored stranded copper power cable (CU/PVC/PVC), 4 cores plus neutral, size 4×25+16 mm², low voltage 0.6/1 kV, produced by Saudi Cables Company (SCC), provides effective protection against mechanical damage and environmental fluctuations.

• Conductor: Stranded Copper
• Insulation Material: PVC type 1 to BS6746 rated 70°C
• Outer Sheath: PVC type ST2 to IEC 502
• Voltage: 0.6/1kV
• Number of Cores: 4 Core + Neutral Line
• Conductor Size (Cross-Sectional Area): ( 4cx25 mm2 ) + 16 mm2
• Number of Phase Wires: 6
• Number of Neutral Wires: 7
• Nominal Insulation Thickness of Phase: 1.2 mm
• Nominal Insulation Thickness of Neutral: 1 mm
• Nominal Sheath Thickness: 1.8 mm
• Approx Overall Diameter: 25.7 mm
• Weight: 1450 kg/km
• Length: 500 meters
• Phase Core Colors: (Red, Yellow, Blue, Black, Green/Yellow)
• Sheath Color: Black
• Standard: IEC: 502
• Catalogue Number: EJHB-54A

Unarmored stranded copper power cable (CU/PVC/PVC), 4 cores plus neutral, size 4×25+16 mm², low voltage 0.6/1 kV, produced by Saudi Cables Company (SCC), suitable for heavy electrical loads and ensures current stability due to its solid construction.

• Conductor: Stranded Copper
• Insulation Material: PVC type 1 to BS6746 rated 70°C
• Outer Sheath: PVC type ST2 to IEC 502
• Voltage: 0.6/1kV
• Number of Cores: 4 Core + Neutral Line
• Conductor Size (Cross-Sectional Area): ( 4cx25 mm2 ) + 16 mm2
• Number of Phase Wires: 6
• Number of Neutral Wires: 7
• Nominal Insulation Thickness of Phase: 1.2 mm
• Nominal Insulation Thickness of Neutral: 1 mm
• Nominal Sheath Thickness: 1.8 mm
• Approx Overall Diameter: 25.7 mm
• Weight: 1450 kg/km
• Length: 1000 meters
• Phase Core Colors: (Red, Yellow, Blue, Black, Green/Yellow)
• Sheath Color: Black
• Standard: IEC: 502
• Catalogue Number: EJHB-54A

Unarmored stranded copper power cable (CU/PVC/PVC), 4 cores plus neutral, size 4×25+16 mm², low voltage 0.6/1 kV, produced by Saudi Cables Company (SCC), perfectly insulated against electricity and moisture and known for its long service life.

• Conductor: Stranded Copper
• Insulation Material: Heat resistant PVC type 5 to BS6746 rated 85°C
• Outer Sheath: PVC type ST2 to IEC 502
• Voltage: 0.6/1kV
• Number of Cores: 4 Core + Neutral Line
• Conductor Size (Cross-Sectional Area): ( 4cx25 mm2 ) + 16 mm2
• Number of Phase Wires: 6
• Number of Neutral Wires: 7
• Nominal Insulation Thickness of Phase: 1.2 mm
• Nominal Insulation Thickness of Neutral: 1 mm
• Nominal Sheath Thickness: 1.8 mm
• Approx Overall Diameter: 25.7 mm
• Weight: 1450 kg/km
• Length: 500 meters
• Phase Core Colors: (Red, Yellow, Blue, Black, Green/Yellow)
• Sheath Color: Black
• Standard: IEC: 502
• Catalogue Number: EJHB-54A
