Stranded PVC Copper Cable 4 Core 4×185+95 mm, 0.6/1kV | SCC
Unarmored stranded copper cable (CU/PVC/PVC), four core plus neutral, size 4×185+95 mm², low voltage 0.6/1 kV, produced by Saudi Cables Company (SCC), offers excellent transmission flexibility and high resistance to abrasion and corrosion.
- Conductor: Stranded Copper
- Insulation Material: PVC type 1 to BS6746 rated 70°C
- Outer Sheath: PVC type ST2 to IEC 502
- Voltage: 0.6/1kV
- Number of Cores: 4 Core + Neutral Line
- Conductor Size (Cross-Sectional Area): ( 4cx185 mm2 ) + 95 mm2
- Number of Phase Wires: 30
- Number of Neutral Wires: 19
- Nominal Insulation Thickness of Phase: 2.0 mm
- Nominal Insulation Thickness of Neutral: 1.6 mm
- Nominal Sheath Thickness: 2.6 mm
- Approx Overall Diameter: 51.8 mm
- Weight: 7470 kg/km
- Length: 250 meters
- Phase Core Colors: (Red, Yellow, Blue, Black, Green/Yellow)
- Sheath Color: Black
- Standard: IEC: 502
- Catalogue Number: EJHB-66A
