Stranded PVC Copper Cable 4 Core 35 mm, 0.6/1kV | Riyadh Cables
4 core electrical stranded copper cable (CU/PVC/PVC), It has a longer lifespan, is resistant to weather influences, and is more resistant to corrosion, 35×4 mm2, color (red, yellow, blue, black), produced by Riyadh Cables Company.
- Insulation : PVC
- Outer jacket : PVC
- Voltage : 600/1000 volts
- Wire type: sectoral stranded
- Number of Cores: 4
- Size (cross-sectional area) : 35 mm2
- Number of wires : 6
- Thickness of insulation layer: 1.2 mm
- Thickness of Sheath: 1.8 mm
- Approx overall diameter: 28 mm
- Weight: 1800 kg/km
- Length : 1000 meters
- Color: (red, yellow, blue, black)
Contact Us
Related products
Stranded PVC Copper Cable 4 Core 35 mm, 0.6/1kV | Riyadh Cables
Four core electrical stranded copper cable (CU/PVC/PVC), Length 1000 metres, it is used in electrical distribution panels, in applications where there is a risk of mechanical damage, Size 35×4 mm2, produced by Riyadh Cables Company.
- Insulation Material: PVC (Polyvinyl Chloride)
- Outer jacket : PVC
- Voltage : 600/1000 volts
- Wire Type: Sectoral Stranded (sm)
- Number of Cores: 4 Core
- Size (cross-sectional area) : 35 mm2
- Number of wires : 6
- Thickness of first insulation layer : 1.2 mm
- Thickness of outer jacket layer : 1.8 mm
- Approx overall diameter : 28 mm
- Weight : 1800 kg/km
- Length : 1000 meters
- Phase Core Color: Blue, Brown, Black, Gray
- Conformity According to International Standard: IEC 60502-1
