Stranded PVC Copper Cable 3 Core 4 mm, 300/500V | SCC
Stranded copper flat cable, 3-core, 2.5mm²(CU/PVC/PVC), insulated up to 70°C with a black PVC sheath, protecting the cable from harsh environmental factors, ensuring flexibility for installation in outdoor areas. Supplied in 50-meter rolls. Produced by Saudi Cable Company.
- Conductor: Stranded Copper
- Insulation Material: PVC type 5 to BS:6746 rated 70°C
- Outer Sheath: PVC type ST2 to IEC:502
- Voltage: 300/500 volts
- Number of Cores: 3
- Conductor Size (Cross-Sectional Area): 4mm2
- Number of Wires: 7
- Nominal Insulation Thickness: 0.8 mm
- Nominal Sheath Thickness: 1.1 mm
- Overall Diameter: 16.5×7.4 mm
- Weight: 216 kg/km
- Length: 50 meter / Coil
- Insulation Color: (Red, Yellow, Blue)
- Sheath Color: Black
- Standards: SASO:55 specification and similar to BS:6004-1984 specification
- Catalogue Number: CBF3-06H
Related products
Stranded PVC Copper Cable 3 Core 4 mm, 300/500V | SCC
Stranded copper electrical flat cable 4 mm with earth conductor (CU/PVC/PVC), low voltage 300/500V, gray color, produced by Saudi Cable Company (SCC). Insulated and sheathed with PVC 70°C, the first layer provides excellent electrical insulation against electrical currents. Suitable for use in both indoor and outdoor wiring.
- Conductor: Stranded Copper
- Insulation Material: PVC type 5 to BS:6746 rated 70°C
- Outer Sheath: PVC type ST2 to IEC:502
- Voltage: 300/500 volts
- Number of Cores: 3
- Conductor Size (Cross-Sectional Area): 4mm2
- Number of Wires: 7
- Earth Continuity Conductor (no.xmm): 1×1.38 mm
- Nominal Insulation Thickness: 0.8 mm
- Nominal Sheath Thickness: 1.1 mm
- Overall Diameter: 18.0×7.4 mm
- Weight: 250 kg/km
- Length: 100 meter / Coil
- Insulation Color: (Red, Yellow, Blue)
- Sheath Color: Gray
- Standards: SASO:55 specification and similar to BS:6004-1984 specification
- Catalogue Number: CBG3-06H
Related products
Stranded PVC Copper Cable 3 Core 4 mm, 300/500V | SCC
Stranded copper flat cable, 3-core, 2.5mm² (CU/PVC/PVC), insulated up to 70°C with a grey PVC sheath that is resistant to weather conditions. Suitable for residential and commercial buildings. Supplied in 100-meter rolls. Produced by Saudi Cable Company.
- Conductor: Stranded Copper
- Insulation Material: PVC type 5 to BS:6746 rated 70°C
- Outer Sheath: PVC type ST2 to IEC:502
- Voltage: 300/500 volts
- Number of Cores: 3
- Conductor Size (Cross-Sectional Area): 4mm2
- Number of Wires: 7
- Nominal Insulation Thickness: 0.8 mm
- Nominal Sheath Thickness: 1.1 mm
- Overall Diameter: 16.5×7.4 mm
- Weight: 216 kg/km
- Length: 100 meter / Coil
- Insulation Color: (Red, Yellow, Blue)
- Sheath Color: Grey
- Standards: SASO:55 specification and similar to BS:6004-1984 specification
- Catalogue Number: CBF3-06H
Related products
Stranded PVC Copper Cable 3 Core 4 mm, 300/500V | SCC
Stranded copper flat cable, 3-core, 2.5mm²(CU/PVC/PVC), insulated up to 70°C with a black PVC sheath, enhancing the cable’s durability in outdoor and damp environments. Ideal for electrical systems in open spaces. Supplied in 100-meter rolls. Produced by Saudi Cable Company.
- Conductor: Stranded Copper
- Insulation Material: PVC type 5 to BS:6746 rated 70°C
- Outer Sheath: PVC type ST2 to IEC:502
- Voltage: 300/500 volts
- Number of Cores: 3
- Conductor Size (Cross-Sectional Area): 4mm2
- Number of Wires: 7
- Nominal Insulation Thickness: 0.8 mm
- Nominal Sheath Thickness: 1.1 mm
- Overall Diameter: 16.5×7.4 mm
- Weight: 216 kg/km
- Length: 100 meter / Coil
- Insulation Color: (Red, Yellow, Blue)
- Sheath Color: Black
- Standards: SASO:55 specification and similar to BS:6004-1984 specification
- Catalogue Number: CBF3-06H
Related products
Stranded PVC Copper Cable 3 Core 4 mm, 300/500V | SCC
Stranded copper flat cable, 3-core, 2.5mm², insulated up to 85°C with a black PVC sheath, offering high protection against corrosion and damage from harsh environmental conditions. Ideal for outdoor applications. Supplied in 50-meter rolls. Produced by Saudi Cable Company.
- Conductor: Stranded Copper
- Insulation Material: PVC type 5 to BS:6746 rated 85°C
- Outer Sheath: PVC type ST2 to IEC:502
- Voltage: 300/500 volts
- Number of Cores: 3
- Conductor Size (Cross-Sectional Area): 4mm2
- Number of Wires: 7
- Nominal Insulation Thickness: 0.8 mm
- Nominal Sheath Thickness: 1.1 mm
- Overall Diameter: 16.5×7.4 mm
- Weight: 216 kg/km
- Length: 50 meter / Coil
- Insulation Color: (Red, Yellow, Blue)
- Sheath Color: Black
- Standards: SASO:55 specification and similar to BS:6004-1984 specification
- Catalogue Number: CGF3-06H
Related products
Stranded PVC Copper Cable 3 Core 4 mm, 300/500V | SCC
Stranded copper flat cable, 3-core, 2.5mm² (CU/PVC/PVC), insulated up to 85°C with a grey PVC sheath, providing additional protection against environmental factors. Ideal for use in industrial facilities with high requirements. Supplied in 50-meter rolls. Produced by Saudi Cable Company.
- Conductor: Stranded Copper
- Insulation Material: PVC type 5 to BS:6746 rated 85°C
- Outer Sheath: PVC type ST2 to IEC:502
- Voltage: 300/500 volts
- Number of Cores: 3
- Conductor Size (Cross-Sectional Area): 4mm2
- Number of Wires: 7
- Nominal Insulation Thickness: 0.8 mm
- Nominal Sheath Thickness: 1.1 mm
- Overall Diameter: 16.5×7.4 mm
- Weight: 216 kg/km
- Length: 50 meter / Coil
- Insulation Color: (Red, Yellow, Blue)
- Sheath Color: Grey
- Standards: SASO:55 specification and similar to BS:6004-1984 specification
- Catalogue Number: CGF3-06H
Related products
Stranded PVC Copper Cable 3 Core 4 mm, 300/500V | SCC
Stranded copper electrical flat cable 4 mm with earth conductor (CU/PVC/PVC), low voltage 300/500V, gray color, produced by Saudi Cable Company (SCC). Insulated and sheathed with PVC 85°C, the first layer provides excellent electrical insulation. Ideal for use in indoor and outdoor wiring of residential and commercial buildings.
- Conductor: Stranded Copper
- Insulation Material: PVC type 5 to BS:6746 rated 85°C
- Outer Sheath: PVC type ST2 to IEC:502
- Voltage: 300/500 volts
- Number of Cores: 3
- Conductor Size (Cross-Sectional Area): 4mm2
- Number of Wires: 7
- Earth Continuity Conductor (no.xmm): 1×1.38 mm
- Nominal Insulation Thickness: 0.8 mm
- Nominal Sheath Thickness: 1.1 mm
- Overall Diameter: 18.0×7.4 mm
- Weight: 250 kg/km
- Length: 100 meter / Coil
- Insulation Color: (Red, Yellow, Blue)
- Sheath Color: Gray
- Standards: SASO:55 specification and similar to BS:6004-1984 specification
- Catalogue Number: CGG3-06H
Related products
Stranded PVC Copper Cable 3 Core 4 mm, 300/500V | SCC
Stranded copper electrical flat cable 4 mm with earth conductor (CU/PVC/PVC), low voltage 300/500V, black color, Produced by Saudi Cable Company (SCC). Insulated and sheathed with PVC 70°C, the first layer provides excellent electrical insulation against electrical currents. Ideal for indoor and outdoor electrical wiring.
- Conductor: Stranded Copper
- Insulation Material: PVC type 5 to BS:6746 rated 70°C
- Outer Sheath: PVC type ST2 to IEC:502
- Voltage: 300/500 volts
- Number of Cores: 3
- Conductor Size (Cross-Sectional Area): 4mm2
- Number of Wires: 7
- Earth Continuity Conductor (no.xmm): 1×1.38 mm
- Nominal Insulation Thickness: 0.8 mm
- Nominal Sheath Thickness: 1.1 mm
- Overall Diameter: 18.0×7.4 mm
- Weight: 250 kg/km
- Length: 100 meter / Coil
- Insulation Color: (Red, Yellow, Blue)
- Sheath Color: Black
- Standards: SASO:55 specification and similar to BS:6004-1984 specification
- Catalogue Number: CBG3-06H
