Stranded Copper Cable Three Core 2.5mm2, 300/500 Rated Voltage, Flat and Earth, Solid PVC Insulated and Sheathed | Riyadh Cables
3 core solid electrical copper cable (CU/PVC/PVC), 2.5 mm2 cross-sectional area, 300/500V, the first layer provides excellent electrical insulation, insulation color is red, yellow and blue, produced by Riyadh Cables Company.
- Conductor: Copper
- Conductor Shape: Solid as per BS EN 60228
- Insulation Material: PVC (Polyvinyl Chloride)
- Outer Sheath: PVC
- Voltage: 300/500 volts
- Number of Cores: 3
- Conductor Size (Cross-Sectional Area): 2.5 mm
- Number of Wires: 1
- Insulation Thickness: 0.8 mm
- Sheath Thickness: 0.9 mm
- Overall Diameter or Dimensions: Lower Limit 5.2 x 12.5 mm / Upper Limit 6.2 x 14.5 mm
- Max DC Conductor Resistance at 20°C: 7.41 ohm/km
- Weight: 180 kg/km
- Insulation Color: (Red & Yellow & Blue)
- Sheath Color: Gray
- Standard: BS 6004
