Stranded Copper Cable Single Core 500 mm, 0.6/1kV, PVC 85°C Insulated, Red Color, 500 m | SCC

Unarmored stranded copper power cable (CU/PVC/PVC), single core, 500mm², low voltage 0.6/1kV, widely used in construction and infrastructure projects. Offers reliable electrical transmission with high flexibility. Produced by Saudi Cables Company.

• Conductor: Stranded Copper
• Insulation Material: PVC type 5 to BS6746 rated 85°C
• Outer Sheath: PVC type ST2 to IEC:502
• Voltage: 0.6/1kV
• Number of Cores: 1
• Conductor Size: 500 mm²
• Number of wires: 53
• Nominal Insulation Thickness: 2.8 mm
• Nominal Sheath Thickness: 2.1 mm
• Approx Overall Diameter: 37.8 mm
• Weight: 5290 kg/km
• Standard Length: 500 meters
• Insulation Color: Red
• Sheath Color: Black
• Standard: IEC: 502
• Catalogue Number: EJB1-28A
