Stranded Copper Cable Four Core 1.5mm, 300/500V, Size, Solid PVC Insulation, PVC Sheath | Riyadh Cables

4 core solid electrical copper cable (CU/PVC/PVC), 1.5 mm2 cross-sectional area, 300/500V, insulated and sheathed with high quality PVC compound (polyvinyl chloride), insulation color is red, yellow, blue and black, produced by Riyadh Cables Company.

• Conductor: Copper
• Conductor Shape: Solid
• Insulation Material: PVC (Polyvinyl Chloride)
• Outer Sheath: PVC
• Voltage: 300/500 volts
• Number of Cores: 4
• Conductor Size (Cross-Sectional Area): 1.5 mm
• Number of Wires: 1
• Approx Conductor Diameter: 1.38 mm
• Insulation Thickness: 0.7
• Sheath Thickness: 1.2 mm
• Overall Diameter: 11.5 mm
• Weight: 165 kg/km
• Max DC Conductor Resistance at 20°C: 12.1 ohm/km
• Standard Packing Length: 100 meter coil
• Insulation Color: (Red & Yellow & Blue & Black)
• Outer Sheath Color: Gray
• Standards: IEC 60227, SSA 1450
