Stranded Copper Cable Five Core 6mm, 600/1000 volts, Solid, PVC Insulated and Sheathed | Alfanar

Cable 6 mm2 five core 600/1000 volts, solid copper, PVC insulated and sheathed, insulation color (red, yellow, blue, black, yellow/green), it is used for transferring electrical signals between different control units and also used in alarm systems., produced by Alfanar Company.

• Conductor: Copper
• Conductor Shape: Plain annealed solid copper conductor class 1 as per IEC 60228
• Insulation Material: PVC (Polyvinyl Chloride) 70 °C
• Outer Sheath: PVC
• Voltage: 600/1000 volts
• Number of Cores: 5
• Conductor Size (Cross-Sectional Area): 6 mm2
• Number of Wires: 1
• Wire Diameter: 2.76 mm
• Nominal Insulation Thickness: 1 mm
• Nominal Sheath Thickness: 1.8 mm
• Overall Diameter: 16.5 mm
• Weight: 610 kg/km
• Standard Packing Length: 1000 meters on wooden drum (Other lengths are available upon request)
• Insulation Color: (Red, Yellow, Blue, Black, Yellow/Green)
• Standard: IEC 60502-1
