Stranded Copper Cable Five Core 4mm2, 300/500 Rated Voltage, Riyadh, Solid, PVC Insulated

5 core solid copper cable, 4 mm size conductor, 300/500 volts, PVC insulated, PVC sheathed, insulation color is black, brown, blue, black and brown, the first layer provides excellent electrical insulation. The outer jacket also provides protection for the cable from corrosion and external factors, produced by Riyadh Cables Company.

• Conductor: Copper
• Conductor Shape: Solid
• Insulation Material: PVC (Polyvinyl Chloride)
• Outer Sheath: PVC
• Voltage: 300/500 volts
• Number of Cores: 5
• Conductor Size (Cross-Sectional Area): 4 mm
• Number of Wires: 1
• Approx Conductor Diameter: 2.25 mm
• Insulation Thickness: 0.8
• Sheath Thickness: 1.4 mm
• Overall Diameter: 16 mm
• Weight: 405 kg/km
• Max DC Conductor Resistance at 20°C: 4.61 ohm/km
• Standard Packing Length: 100 meter coil
• Insulation Color: (Black, Brown, Blue, Black, Brown)
• Outer Sheath Color: Gray
• Standards: IEC 60227, SSA 1450
