Stranded Copper Cable Five Core 10 sq mm, 300/500V, Riyadh, Solid, PVC Insulated

5 core solid copper cable, 10 mm size conductor, 300/500 volts, PVC insulated, PVC sheathed, insulation color is black, brown, blue, black and brown, produced by Riyadh Cables Company, according to international standards, ensuring its quality and performance.

• Conductor: Copper
• Conductor Shape: Solid
• Insulation Material: PVC (Polyvinyl Chloride)
• Outer Sheath: PVC
• Voltage: 300/500 volts
• Number of Cores: 5
• Conductor Size (Cross-Sectional Area): 10 mm
• Number of Wires: 1
• Approx Conductor Diameter: 3.57 mm
• Insulation Thickness: 1
• Sheath Thickness: 1.4 mm
• Overall Diameter: 21 mm
• Weight: 810 kg/km
• Max DC Conductor Resistance at 20°C: 1.83 ohm/km
• Standard Packing Length: 1000/2000 meter
• Insulation Color: (Black, Brown, Blue, Black, Brown)
• Outer Sheath Color: Gray
• Standards: IEC 60227, SSA 1450
