Stranded Copper Cable Five Core 1.5mm2, 300/500 volts, Solid, Size Conductor, PVC Insulation | Alfanar

Solid copper cable, 1.5 mm2 size conductor, five core, 300/500 volts, PVC insulation provides excellent electrical insulation, while the PVC sheath protects the cable from corrosion and external environmental factors, insulation color (red, yellow, blue, black, yellow/green), from Alfanar.

• Conductor: Copper
• Conductor Shape: Plain annealed solid copper conductor class 1 as per IEC 60228
• Insulation Material: PVC (Polyvinyl Chloride) 70 °C
• Outer Sheath: PVC
• Voltage: 300/500 volts
• Cable Type: (H05VV-U)
• Number of Cores: 5
• Conductor Size (Cross-Sectional Area): 1.5 mm2
• Number of Wires: 1
• Wire Diameter: 1.38 mm
• Nominal Insulation Thickness: 0.7 mm
• Thickness of Inner Covering: 0.4 mm
• Nominal Sheath Thickness: 1.2 mm
• Overall Diameter: 10.7 mm
• Weight: 200 kg/km
• Standard Packing Length: 1000 meters on wooden drum (Other lengths are available upon request)
• Insulation Color: (Red, Yellow, Blue, Black, Yellow/Green)
• Standard: IEC 60227-4
