Stranded Copper Cable Five Core 1.5mm, 300/500V, Riyadh, Solid, PVC Insulated

5 core solid copper cable, 1.5 mm size conductor, 300/500 volts, PVC insulated, PVC sheathed, insulation color is black, brown, blue, black and brown, available in a variety of sizes and colors with highest quality and best prices, produced by Riyadh Cables Company.

• Conductor: Copper
• Conductor Shape: Solid
• Insulation Material: PVC (Polyvinyl Chloride)
• Outer Sheath: PVC
• Voltage: 300/500 volts
• Number of Cores: 5
• Conductor Size (Cross-Sectional Area): 1.5 mm
• Number of Wires: 1
• Approx Conductor Diameter: 1.38 mm
• Insulation Thickness: 0.7
• Sheath Thickness: 1.2 mm
• Overall Diameter: 12 mm
• Weight: 195 kg/km
• Max DC Conductor Resistance at 20°C: 12.1 ohm/km
• Standard Packing Length: 100 meter coil
• Insulation Color: (Black, Brown, Blue, Black, Brown)
• Outer Sheath Color: Gray
• Standards: IEC 60227, SSA 1450
