Stranded Copper Cable 6 mm, 0.6/1kV, Solid PVC, 2× | Riyadh Cables

Two core electrical cable (CU/PVC/PVC), solid copper conductor, It is used to conduct electrical current in various domestic, commercial and industrial applications, produced by Riyadh Cables Company, Size 6 mm2.

• Insulation Material: PVC (Polyvinyl Chloride)
• Outer Sheath: PVC
• Voltage : 600/1000 volts
• Conductor Shape: Solid (re)
• Number of Cores: 2 Core
• Conductor Size (Cross-Sectional Area): 6 mm2
• Number of Wires: 1
• Approx Conductor Diameter: 2.76 mm
• Nominal Insulation Thickness: 1 mm
• Nominal Sheath Thickness: 1.8 mm
• Approx Overall Diameter: 16 mm
• Weight: 375 kg/km
• Length : 1000 meters
• Phase Core Colors: (Red, Black)
• Standard: IEC 60502-1
