Stranded Copper Cable 5 Core 4mm2, 300/500 volts, Solid, Size, PVC Insulation | Alfanar

Solid copper electrical cable, 5 core, 4 mm2 size, 300/500 volts, insulation color (red, yellow, blue, black, yellow/green), insulated and sheathed with PVC, available in a variety of sizes and colors with highest quality and best prices, produced by Alfanar Company.

• Conductor: Copper
• Conductor Shape: Plain annealed solid copper conductor class 1 as per IEC 60228
• Insulation Material: PVC (Polyvinyl Chloride) 70 °C
• Outer Sheath: PVC
• Voltage: 300/500 volts
• Cable Type: (H05VV-U)
• Number of Cores: 5
• Conductor Size (Cross-Sectional Area): 4 mm2
• Number of Wires: 1
• Wire Diameter: 2.25 mm
• Nominal Insulation Thickness: 0.8 mm
• Thickness of Inner Covering: 0.6 mm
• Nominal Sheath Thickness: 1.4 mm
• Overall Diameter: 14.4 mm
• Weight: 495 kg/km
• Standard Packing Length: 1000 meters on wooden drum (Other lengths are available upon request)
• Insulation Color: (Red, Yellow, Blue, Black, Yellow/Green)
• Standard: IEC 60227-4
