Stranded Copper Cable 5 Core 2.5sq mm, 300/500 Voltage Rating, Solid, Size, PVC Insulation | Alfanar

Solid electrical copper cable 5 core (CU/PVC/PVC), 2.5 mm2 cross-sectional area, 300/500V, the insulation and sheath material is polyvinyl chloride (PVC), insulation color (red, yellow, blue, black, yellow/green), produced by Alfanar Company according to the international standard IEC 60227-4, which ensures its quality and performance.

• Conductor: Copper
• Conductor Shape: Plain annealed solid copper conductor class 1 as per IEC 60228
• Insulation Material: PVC (Polyvinyl Chloride) 70 °C
• Outer Sheath: PVC
• Voltage: 300/500 volts
• Cable Type: (H05VV-U)
• Number of Cores: 5
• Conductor Size (Cross-Sectional Area): 2.5 mm2
• Number of Wires: 1
• Wire Diameter: 1.78 mm
• Nominal Insulation Thickness: 0.8 mm
• Thickness of Inner Covering: 0.4 mm
• Nominal Sheath Thickness: 1.4 mm
• Overall Diameter: 12.3 mm
• Weight: 280 kg/km
• Standard Packing Length: 1000 meters on wooden drum (Other lengths are available upon request)
• Insulation Color: (Red, Yellow, Blue, Black, Yellow/Green)
• Standard: IEC 60227-4
