Stranded Copper Cable 3 Core 6mm, 0.6/1kV, CU/PVC/PVC Size, Solid, 1000 meter | RESCAB

Solid copper power cable (CU/PVC/PVC), 3 phase, 6mm2 size conductor, 0.6/1kV, Withstands high temperatures without affecting its performance, resists water and moisture, insulation color is red, yellow, blue, produced by Red Sea Cables Company (RESCAB).

• Conductor: Solid Copper
• Insulation Material: PVC (Polyvinyl Chloride)
• Outer Sheath: PVC
• Voltage: 0.6/1kV
• Number of Cores: 3
• Conductor Size (Cross-Sectional Area): 6 mm2
• Number of wires: 1
• Nominal Insulation Thickness: 1.0 mm
• Nominal Sheath Thickness: 1.8 mm
• Approx Overall Diameter: 17 mm
• Max DC Conductor Resistance at 20°C: 3.08 ohm/km
• Weight: 450 kg/km
• Standard Length: 1000 meters
• Phase Core Color: red, yellow, blue
• Standard: IEC 60502-1
