Stranded Copper Cable 3 Core 2.5mm, 300/500 Volts, Size, Solid, PVC Insulated | Riyadh Cables

3 core solid electrical copper cable (CU/PVC/PVC), 2.5 mm2 cross-sectional area, 300/500V, insulation color is brown, blue and black, produced by Riyadh Cables Company, according to international standards, ensuring its quality and performance, insulated and sheathed with high quality PVC compound (polyvinyl chloride).

• Conductor: Copper
• Conductor Shape: Solid
• Insulation Material: PVC (Polyvinyl Chloride)
• Outer Sheath: PVC
• Voltage: 300/500 volts
• Number of Cores: 3
• Conductor Size (Cross-Sectional Area): 2.5 mm
• Number of Wires: 1
• Approx Conductor Diameter: 1.78 mm
• Insulation Thickness: 0.8
• Sheath Thickness: 1.2 mm
• Overall Diameter: 12 mm
• Weight: 195 kg/km
• Max DC Conductor Resistance at 20°C: 7.41 ohm/km
• Standard Packing Length: 100 meter coil
• Insulation Color: (Brown & Blue & Black)
• Outer Sheath Color: Gray
• Standards: IEC 60227, SSA 1450
