Stranded Copper Cable 3 Core 10 sq mm, 300/500V, Size, Solid, PVC Insulation | Riyadh Cables

3 core solid copper cable, 10 mm size conductor, 300/500 volts, PVC insulated, PVC sheathed, insulation color is brown, blue and black, produced by Riyadh Cables Company, according to international standards, ensuring its quality and performance.

• Conductor: Copper
• Conductor Shape: Solid
• Insulation Material: PVC (Polyvinyl Chloride)
• Outer Sheath: PVC
• Voltage: 300/500 volts
• Number of Cores: 3
• Conductor Size (Cross-Sectional Area): 10 mm
• Number of Wires: 1
• Approx Conductor Diameter: 3.57 mm
• Insulation Thickness: 1
• Sheath Thickness: 1.4 mm
• Overall Diameter: 17.5 mm
• Weight: 540 kg/km
• Max DC Conductor Resistance at 20°C: 1.83 ohm/km
• Standard Packing Length: 1000/2000 meter
• Insulation Color: (Brown & Blue & Black)
• Outer Sheath Color: Gray
• Standards: IEC 60227, SSA 1450
