Stranded Copper Cable 2 Core 4sq mm, 600/1000 Voltage Rating, Solid, PVC Insulated and Sheathed | Alfanar

Solid electrical copper cable 2 core (CU/PVC/PVC), 4 mm2 cross-sectional area, low voltage 600/1000V, insulated and sheathed with PVC, the first layer provides excellent electrical insulation, the outer jacket also provides protection for the cable from corrosion and external factors, insulation color (red, black), produced by Alfanar Company.

• Conductor: Copper
• Conductor Shape: Plain annealed solid copper conductor class 1 as per IEC 60228
• Insulation Material: PVC (Polyvinyl Chloride) 70 °C
• Outer Sheath: PVC
• Voltage: 600/1000 volts
• Number of Cores: 2
• Conductor Size (Cross-Sectional Area): 4 mm2
• Number of Wires: 1
• Wire Diameter: 2.25 mm
• Nominal Insulation Thickness: 1 mm
• Nominal Sheath Thickness: 1.8 mm
• Overall Diameter: 12.1 mm
• Weight: 255 kg/km
• Standard Packing Length: 1000 meters on wooden drum (Other lengths are available upon request)
• Insulation Color: (Red, Black)
• Standard: IEC 60502-1
