Stranded Copper Cable 2 Core 1mm2, 300/500V, Solid, Size, PVC Insulation, PVC Sheath | Alfanar

Solid electrical copper cable 2 core (CU/PVC/PVC), 1 mm2 cross-sectional area, 300/500V, insulated and sheathed with PVC compound (polyvinyl chloride), phase core colors (red, black), produced by Alfanar Company.

• Conductor: Copper
• Conductor Shape: Plain annealed solid copper conductor class 1 as per IEC 60228
• Insulation Material: PVC (Polyvinyl Chloride) 70 °C
• Outer Sheath: PVC
• Voltage: 300/500 volts
• Cable Type: (H05VV-U)
• Number of Cores: 2
• Conductor Size (Cross-Sectional Area): 1 mm2
• Number of Wires: 1
• Wire Diameter: 1.13 mm
• Nominal Insulation Thickness: 0.6
• Thickness of Inner Covering: 0.4 mm
• Nominal Sheath Thickness: 1.2 mm
• Overall Diameter: 7.9 mm
• Weight: 95 kg/km
• Standard Packing Length: 1000 meters on wooden drum (Other lengths are available upon request)
• Insulation Color: (Red, Black)
• Standard: IEC 60227-4
