Single Core Copper Cable 600/1000 V, PVC, Stranded, Size 500 mm2, Blue Color | Riyadh Cables

Stranded single core electrical copper cable PVC. The outer jacket provides protection for the cable from corrosion and external factors, such as lighting equipment, central air conditioners, power sockets, and household appliances, blue color, cross-sectional area 500 mm2, produced by Riyadh Cables Company, in accordance with the international standard (IEC 60502-1).

• Insulation : PVC
• Outer jacket : PVC
• Voltage : 600/1000 volts
• Size (cross-sectional area) : 500 mm2
• Number of wires : 61
• Approx conductor diameter : 28.5 mm
• Thickness of  first insulation layer : 2.8 mm
• Thickness of outer jacket layer : 2.1 mm
• Approx overall diameter : 39 mm
• Weight : 5250 kg/km
• Length : 500 meters
• Color : blue
• According to standard : IEC 60502-1
