Single Core Copper Cable 600/1000 V, PVC, Stranded, Size 240 mm2, Blue Color | Riyadh Cables

Stranded single core electrical copper cable PVC. The insulator is used to prevent the leakage of electricity or current around and for protection. It is a good conductor of electricity, blue color, cross-sectional area 240 mm2, produced by Riyadh Cables Company, in accordance with the international standard (IEC 60502-1).

• Insulation : PVC
• Outer jacket : PVC
• Voltage : 600/1000 volts
• Size (cross-sectional area) : 240 mm2
• Number of wires : 61
• Approx conductor diameter : 20 mm
• Thickness of  first insulation layer : 2.2 mm
• Thickness of outer jacket layer : 1.8 mm
• Approx overall diameter : 28 mm
• Weight : 2600 kg/km
• Length : 1000 meters
• Color : blue
• According to standard : IEC 60502-1
