Single Core Copper Cable 600/1000 V, PVC, Stranded, Size 120 mm2, Blue Color | Riyadh Cables

Stranded single core electrical copper cable PVC. It has high heat resistance, insulated with two layers of high quality PVC, blue color, cross-sectional area 120 mm2, produced by Riyadh Cables Company, in accordance with the international standard (IEC 60502-1).

• Insulation : PVC
• Outer jacket : PVC
• Voltage : 600/1000 volts
• Size (cross-sectional area) : 120 mm2
• Number of wires : 37
• Approx conductor diameter : 14 mm
• Thickness of  first insulation layer : 1.6 mm
• Thickness of outer jacket layer : 1.5 mm
• Approx overall diameter : 21 mm
• Weight : 1325 kg/km
• Length : 1000 meters
• Color : blue
• According to standard : IEC 60502-1
