PVC Copper Cable 600/1000 V, Single Core Stranded, Size 150 mm2, Red Color | Riyadh Cables
PVC copper electrical cable single core stranded, Length 1000 meters, red color, The outer jacket provides protection for the cable from corrosion and external factors, It is used to conduct electrical current, Produced by Riyadh Cables Company, cross-sectional area 150 mm2.
- Insulation : PVC
- Outer jacket : PVC
- Voltage : 600/1000 volts
- Size (cross-sectional area) : 150 mm2
- Number of wires : 37
- Approx conductor diameter : 15.5 mm
- Thickness of first insulation layer : 1.8 mm
- Thickness of outer jacket layer : 1.6 mm
- Approx overall diameter : 23 mm
- Weight : 1600 kg/km
- Length : 1000 meters
- Color : Red
- According to standard : IEC 60502-1
