PVC Copper Cable 600/1000 V, Single Core Stranded, Size 150 mm2, Brown Color | Riyadh Cables

Stranded single core electrical copper cable PVC, Insulated with two layers of high-quality PVC (polyvinyl chloride) material, thickness of first insulation layer 1.8 mm, Produced by Riyadh Cables Company, brown color, cross-sectional area 150 mm2.

• Insulation : PVC
• Outer jacket : PVC
• Voltage : 600/1000 volts
• Size (cross-sectional area) : 150 mm2
• Number of wires : 37
• Approx conductor diameter : 15.5 mm
• Thickness of  first insulation layer : 1.8 mm
• Thickness of outer jacket layer : 1.6 mm
• Approx overall diameter : 23 mm
• Weight : 1600 kg/km
• Length : 1000 meters
• Color : Brown
• According to standard : IEC 60502-1
