6mm Single Core Stranded Copper Cable, 300/500 Volts, PVC Insulation, Red Color | Riyadh Cables

Single core stranded electrical copper cable (CU/PVC/PVC), 6 mm2 cross-sectional area, 300/500V, insulation color is red, produced by Riyadh Cables Company, according to the British standard, ensuring its quality and performance, insulated and sheathed with high quality PVC compound (polyvinyl chloride).

• Conductor: Copper
• Conductor Shape: Stranded as per BS EN 60228
• Insulation Material: PVC (Polyvinyl Chloride)
• Outer Sheath: PVC
• Voltage: 300/500 volts
• Number of Cores: 1
• Conductor Size (Cross-Sectional Area): 6 mm
• Number of Wires: 7
• Insulation Thickness: 0.8 mm
• Sheath Thickness: 0.9 mm
• Overall Diameter or Dimensions: Lower Limit 6 mm / Upper Limit 7.4 mm
• Max DC Conductor Resistance at 20°C: 3.08 ohm/km
• Weight: 96 kg/km
• Insulation Color: Red
• Standard: BS 6004
