4mm Flat and Earth Electrical Cable, 300/500V, Three Core, Stranded Copper PVC Insulation and Sheath | Riyadh Cables
3 core stranded copper cable, 4 mm size conductor, 300/500 volts, PVC insulated, insulation color is brown, black and gray, PVC sheathed, produced by Riyadh Cables Company, where occupying less space when installed on exterior or interior walls of buildings. Available in a variety of sizes and colors.
- Conductor: Copper
- Conductor Shape: Stranded as per BS EN 60228
- Insulation Material: PVC (Polyvinyl Chloride)
- Outer Sheath: PVC
- Voltage: 300/500 volts
- Number of Cores: 3
- Conductor Size (Cross-Sectional Area): 4 mm
- Number of Wires: 7
- Insulation Thickness: 0.8 mm
- Sheath Thickness: 1 mm
- Overall Diameter or Dimensions: Lower Limit 5.8 x 14.5 mm / Upper Limit 7.4 x 18 mm
- Max DC Conductor Resistance at 20°C: 4.61 ohm/km
- Weight: 250 kg/km
- Insulation Color: (Brown, Black, Gray)
- Sheath Color: Gray
- Standard: BS 6004
Contact Us
Related products
4mm Flat and Earth Electrical Cable, 300/500V, Three Core, Stranded Copper PVC Insulation and Sheath | Riyadh Cables
3 core stranded copper cable, 4 mm size conductor, 300/500 volts, PVC insulated, insulation color is red, yellow and blue, PVC sheathed, produced by Riyadh Cables Company, where the outer jacket provides protection for the cable from corrosion and external factors.
- Conductor: Copper
- Conductor Shape: Stranded as per BS EN 60228
- Insulation Material: PVC (Polyvinyl Chloride)
- Outer Sheath: PVC
- Voltage: 300/500 volts
- Number of Cores: 3
- Conductor Size (Cross-Sectional Area): 4 mm
- Number of Wires: 7
- Insulation Thickness: 0.8 mm
- Sheath Thickness: 1 mm
- Overall Diameter or Dimensions: Lower Limit 5.8 x 14.5 mm / Upper Limit 7.4 x 18 mm
- Max DC Conductor Resistance at 20°C: 4.61 ohm/km
- Weight: 250 kg/km
- Insulation Color: (Red, Yellow, Blue)
- Sheath Color: Gray
- Standard: BS 6004
