25 sq mm Single Core Stranded Copper Cable, 300/500V, PVC Insulated, Brown Color | Riyadh Cables

Single core stranded copper cable, 25 mm size conductor, 300/500 volts, PVC insulated, insulation color is brown, the first layer provides excellent electrical insulation. The outer jacket also provides protection for the cable from corrosion and external factors, produced by Riyadh Cables Company.

• Conductor: Copper
• Conductor Shape: Stranded as per BS EN 60228
• Insulation Material: PVC (Polyvinyl Chloride)
• Outer Sheath: PVC
• Voltage: 300/500 volts
• Number of Cores: 1
• Conductor Size (Cross-Sectional Area): 25 mm
• Number of Wires: 7
• Insulation Thickness: 1.2 mm
• Sheath Thickness: 1.1 mm
• Overall Diameter or Dimensions: Lower Limit 10 mm / Upper Limit 12.5 mm
• Max DC Conductor Resistance at 20°C: 0.727 ohm/km
• Weight: 335 kg/km
• Insulation Color: Brown
• Standard: BS 6004
