150 mm 0.6/1kV Single Core Electric Cable , Stranded Wire Conductor, PVC Insulation and Sheath, Red Color, 1000 meter Length | BAHRA

Unarmored stranded copper power electric cable (CU/PVC/PVC), single core,150mm2 size conductor, 0.6/1kV, produced by BAHRA cables company, they are distinguished by their economical cost, reliable performance, It also prevents harmful UV rays from damaging the cable.

• Conductor: Stranded Copper
• Insulation Material: PVC (Polyvinyl Chloride)
• Outer Sheath: PVC
• Voltage: 0.6/1kV
• Number of Cores: 1
• Conductor Size (Cross-Sectional Area): 150 mm2
• Number of wires: 37
• Nominal Insulation Thickness: 1.8 mm
• Nominal Sheath Thickness: 1.6 mm
• Approx Overall Diameter: 22.3 mm
• Weight: 1582 kg/km
• Standard Length: 1000 meters
• Phase Core Color: Red
• Standard: IEC 60502-1
